Factors Affecting the Quality of Metal Stamping

To ensure the quality of stamped parts, we need to focus on a series of influencing factors. From material selection to equipment operation, every link may affect the final product’s precision, surface quality, and production efficiency. Below is a detailed analysis of common factors affecting quality in the stamping process.

1. Die Design and Precision

Improper die clearance: Too large a die clearance can cause burrs, while too small a clearance may hinder material flow, creating stress concentrations.

Die wear: Over time, dies wear out, especially when stamping high-strength materials. This wear can cause dimensional instability.

Inadequate die temperature control: If the die temperature is too high or too low, it can affect the material’s formability, leading to uneven surfaces or cracks in the part.

2. Material Quality and Properties

Uneven thickness: If the material’s thickness is uneven, it can lead to unstable forming, causing deviations or defects.

Hardness variations: Materials with higher hardness are more difficult to form and may develop cracks during the stamping process.

Inconsistent material properties: Impurities or uneven grain structures in the material may make it difficult to form certain areas, affecting the overall quality of the product.

3. Press Machine Performance and Adjustment

Pressure fluctuations: If the press machine experiences significant pressure fluctuations, it can cause uneven part deformation, resulting in dimensional deviations or defective forming.

4. Lubrication System

Uneven lubrication: If the lubricant is not applied evenly, it can cause uneven friction between the die and material, which can affect surface quality and even lead to scratching.

Lubricant accumulation: Excess lubricant may cause the material to slip, impacting the dimensional accuracy of the stamped parts.

Incompatible lubricant type: Different materials may require different types of lubricants, and using the wrong lubricant can lead to poor lubrication effectiveness, thereby affecting stamping quality.

5. Operator Skills

Incorrect parameter settings: If the operator does not correctly set the press machine’s parameters (such as pressure, speed, etc.), it can result in parts with irregular shapes and dimensional deviations.

Improper die alignment: If the operator fails to align the die precisely, it may lead to uneven material distribution in the die, affecting the quality of the finished parts.

Lack of process monitoring: If the operator fails to identify and adjust for abnormalities during the production process, it may lead to the production of defective parts.

6. Material Preprocessing and Storage

Surface contamination: If the material surface has oil, rust, or other contaminants, it can affect lubrication and cause surface scratches or difficulty in stamping.

Improper material storage: If the material is stored in a humid or contaminated environment for long periods, it may corrode, affecting the subsequent stamping quality.

Expired or overused material: Materials stored for extended periods may deteriorate, affecting their ductility and stamping performance.
